Varnish 4 Example with Apache, WordPress, Woocommerce, Memberships, and more.

It was a long journey to get a working Varnish 4.0 to behave with WordPress and all of its dynamic plugins (such as Paid Memberships Pro PMP, Woocommerce, WordPress Social Login, etc), however the journey is not over…yet. I found myself scattered around the internet looking for resources about Varnish and the various scripts I am using. Thus I decided to write this guide and share my Varnish example. I am adding my experience here in hopes I can get feedback from you, the pros and beginners, and hopefully help some people along the way. In terms of Varnish performance and optimization, my goal is to achieve a decent hit rate on static content while leaving dynamic member content dynamic. Cheers!

Subscribe to Psynaps YouTube Watch Psynaps Live on Twitch

About my setup

I am running 5+ wordpress sites on the same server, each with WP Super Cache. I am finding that this config, along with WP Super Cache is making my website very fast (try it www.psynapticmedia.com).

This will work well for multisite, as I am running multiple wordpress sites and each one has a different need for cookie management. For example, I want my blog to be more static and have a high hit rate, however I want my members site to be more dynamic as each member will have a unique session. Of course I want my woocommerce shop to be functional so sales can be processed. You will see the “do not cache” area and the cookie madness below that makes this possible.

A working default.vcl

(updated 06-14-15)

# The Psynaptic Media Varnish Config by Psynaps
# Based on many templates including
# https://github.com/mattiasgeniar/varnish-4.0-configuration-templates/blob/master/default.vcl

vcl 4.0;

import std;
import directors;

backend server1 {
  .host = "127.0.0.1";             # IP or Hostname of backend
  .port = "8080";                  # Port Apache or whatever is listening
  .max_connections = 800;          # That's it
  .first_byte_timeout = 300s;      # How long to wait before we receive a first byte from our backend?
  .connect_timeout = 300s;         # How long to wait for a backend connection?
  .between_bytes_timeout = 300s;   # How long to wait between bytes received from our backend?
}

# Only allow purging from specific IPs
acl purge {
    "localhost";
    "127.0.0.1";
    "104.131.26.178"; # eth0
    "10.132.122.116"; # eth1
    "psynapticmedia.com";
}

sub vcl_init {
  # Called when VCL is loaded, before any requests pass through it. Typically used to initialize VMODs.
  new vdir = directors.round_robin();
  vdir.add_backend(server1);
  #vdir.add_backend(server2);
  #vdir.add_backend(server3);
}


sub vcl_recv {
  # Called at the beginning of a request, after the complete request has been received and parsed.
  # Its purpose is to decide whether or not to serve the request, how to do it, and, if applicable,
  # which backend to use.
  # also used to modify the request

  # send all traffic to the vdir director
  set req.backend_hint = vdir.backend();

  # TURN OFF CACHE when needed (just uncomment this only when needed)
  # return(pass);

  # Allow purging from ACL
  if (req.method == "PURGE") {
    if (!client.ip ~ purge) {
    return(synth(405,"Not allowed."));
    }
    return (purge);
  }


  # Normalize the header, remove the port (in case you're testing this on various TCP ports)
  set req.http.Host = regsub(req.http.Host, ":[0-9]+", "");

  # set or append the client.ip to X-Forwarded-For header. Important for logging and correct IPs.
  if (req.restarts == 0) {
    if (req.http.X-Forwarded-For) {
      set req.http.X-Forwarded-For = req.http.X-Forwarded-For + ", " + client.ip;
    } else {
      set req.http.X-Forwarded-For = client.ip;
    }
  }

###
### Do not Cache: special cases
###

  # Do not cache AJAX requests.
    if (req.http.X-Requested-With == "XMLHttpRequest") {
        return(pass);
    }

  # Post requests will not be cached
    if (req.http.Authorization || req.method == "POST") {
        return (pass);
    }

  # Only cache GET or HEAD requests. This makes sure the POST requests are always passed.
  #if (req.method != "GET" &amp;&amp; req.method != "HEAD") {
  #  return (pass);
  #}

  # Dont Cache Wordpress post pages and edit pages
    if (req.url ~ "(wp-admin|post\.php|edit\.php|wp-login)") {
        return(pass);
    }
    if (req.url ~ "/wp-cron.php" || req.url ~ "preview=true") {
        return (pass);
    }

  # Woocommerce
    if (req.url ~ "(cart|my-account|checkout|addons)") {
        return (pass);
    }
    if ( req.url ~ "\?add-to-cart=" ) {
        return (pass);
    }

  # Paid memberships Pro PMP
    if ( req.url ~ "(membership-account|membership-checkout)" ) {
        return (pass);
    }

  # Wordpress Social Login Plugin. Note: Need to develop this. Please share if you have an example.
    if (req.url ~ "(wordpress-social-login|wp-social-login)") {
        return (pass);
    }

  # WP-Affiliate
    if ( req.url ~ "\?ref=" ) {
        return (pass);
    }

  # phpBB Logged in users and ACP
    if ( req.url ~ "(/forumPM/adm/|ucp.php?mode=|\?mode=edit)" ) {
        return (pass);
    }


###
###    http header Cookie
###    Remove some cookies (if found)
###    Cache This Stuff
###
# https://www.varnish-cache.org/docs/4.0/users-guide/increasing-your-hitrate.html#cookies

  ### COOKIE MADNESS.

    # Remove the "has_js" cookie
    set req.http.Cookie = regsuball(req.http.Cookie, "has_js=[^;]+(; )?", "");

    # Remove any Google Analytics based cookies
    set req.http.Cookie = regsuball(req.http.Cookie, "__utm.=[^;]+(; )?", "");
    set req.http.Cookie = regsuball(req.http.Cookie, "_ga=[^;]+(; )?", "");
    set req.http.Cookie = regsuball(req.http.Cookie, "utmctr=[^;]+(; )?", "");
    set req.http.Cookie = regsuball(req.http.Cookie, "utmcmd.=[^;]+(; )?", "");
    set req.http.Cookie = regsuball(req.http.Cookie, "utmccn.=[^;]+(; )?", "");

    # Remove the Quant Capital cookies (added by some plugin, all __qca)
    set req.http.Cookie = regsuball(req.http.Cookie, "__qc.=[^;]+(; )?", "");

    # Remove the wp-settings-1 cookie
    set req.http.Cookie = regsuball(req.http.Cookie, "wp-settings-1=[^;]+(; )?", "");

    # Remove the wp-settings-time-1 cookie
    set req.http.Cookie = regsuball(req.http.Cookie, "wp-settings-time-1=[^;]+(; )?", "");

    # Remove the wp test cookie
    set req.http.Cookie = regsuball(req.http.Cookie, "wordpress_test_cookie=[^;]+(; )?", "");

    # Remove the phpBB cookie. This will help us cache bots and anonymous users.
    set req.http.Cookie = regsuball(req.http.Cookie, "style_cookie=[^;]+(; )?", "");
    set req.http.Cookie = regsuball(req.http.Cookie, "phpbb3_psyfx_track=[^;]+(; )?", "");

    # Remove the cloudflare cookie
    set req.http.Cookie = regsuball(req.http.Cookie, "__cfduid=[^;]+(; )?", "");

    # Remove the PHPSESSID in members area cookie
    set req.http.Cookie = regsuball(req.http.Cookie, "PHPSESSID=[^;]+(; )?", "");

    # Are there cookies left with only spaces or that are empty?
    if (req.http.cookie ~ "^\s*$") {
    unset req.http.cookie;
    }

  # MEGA DROP. Drop ALL cookies sent to WordPress, except those originating from the URLs defined.
  # This increases HITs significantly, but be careful it can also break plugins that need cookies.
  # Note: The /members/ directory had problems with PMP login and social login plugin.
  # Adding it to the exclude list here (and including it below in the "Retain cookies" list) fixed login.
  # This works better than than other cookie removal examples found on varnish's website.
  # Note phpBB directory (forumPM) also passes cookies here.
  if (!(req.url ~ "(wp-login|wp-admin|cart|my-account|checkout|addons|wordpress-social-login|wp-login\.php|forumPM|members)")) {
  unset req.http.cookie;
  }

  # Normalize the query arguments.
  # Note: Placing this above the "do not cache" section breaks some WP theme elements and admin functionality.
  set req.url = std.querysort(req.url);

  # Large static files are delivered directly to the end-user without
  # waiting for Varnish to fully read the file first.
  # Varnish 4 fully supports Streaming, so see do_stream in vcl_backend_response() to witness the glory.
  if (req.url ~ "^[^?]*\.(mp[34]|rar|tar|tgz|wav|zip|bz2|xz|7z|avi|mov|ogm|mpe?g|mk[av])(\?.*)?$") {
    unset req.http.Cookie;
    return (hash);
  }

  # Cache all static files by Removing all cookies for static files
  # Remember, do you really need to cache static files that don't cause load? Only if you have memory left.
  # Here I decide to cache these static files. For me, most of them are handled by the CDN anyway.
  if (req.url ~ "^[^?]*\.(bmp|bz2|css|doc|eot|flv|gif|ico|jpeg|jpg|js|less|pdf|png|rtf|swf|txt|woff|xml)(\?.*)?$") {
    unset req.http.Cookie;
    return (hash);
  }

  # Cache all static files by Removing all cookies for static files - These file extensions are generated by WP Super Cache.
  if (req.url ~ "^[^?]*\.(html|htm|gz)(\?.*)?$") {
    unset req.http.Cookie;
    return (hash);
  }

  # Do not cache Authorized requests.
    if (req.http.Authorization) {
        return(pass);
    }

 # Cache all others requests.
 # Note Varnish v4: vcl_recv must now return hash instead of lookup
    return (hash);
}


sub vcl_pipe {
  # Called upon entering pipe mode.
  # In this mode, the request is passed on to the backend, and any further data from both the client
  # and backend is passed on unaltered until either end closes the connection. Basically, Varnish will
  # degrade into a simple TCP proxy, shuffling bytes back and forth. For a connection in pipe mode,
  # no other VCL subroutine will ever get called after vcl_pipe.

  # Note that only the first request to the backend will have
  # X-Forwarded-For set.  If you use X-Forwarded-For and want to
  # have it set for all requests, make sure to have:
  # set bereq.http.connection = "close";
  # here.  It is not set by default as it might break some broken web
  # applications, like IIS with NTLM authentication.

  # set bereq.http.Connection = "Close";

  return (pipe);
}


sub vcl_pass {
  # Called upon entering pass mode. In this mode, the request is passed on to the backend, and the
  # backend's response is passed on to the client, but is not entered into the cache. Subsequent
  # requests submitted over the same client connection are handled normally.

  # return (pass);
}


# The data on which the hashing will take place
sub vcl_hash {
  # Called after vcl_recv to create a hash value for the request. This is used as a key
  # to look up the object in Varnish.

  hash_data(req.url);

  if (req.http.host) {
    hash_data(req.http.host);
  } else {
    hash_data(server.ip);
  }

  # hash cookies for requests that have them
  if (req.http.Cookie) {
    hash_data(req.http.Cookie);
  }

  # If the client supports compression, keep that in a different cache
  if (req.http.Accept-Encoding) {
      hash_data(req.http.Accept-Encoding);
  }

  return (lookup);
}


# Handle the HTTP request coming from our backend
sub vcl_backend_response {
  # Called after the response headers has been successfully retrieved from the backend.

  # Sometimes, a 301 or 302 redirect formed via Apache's mod_rewrite can mess with the HTTP port that is being passed along.
  # This often happens with simple rewrite rules in a scenario where Varnish runs on :80 and Apache on :8080 on the same box.
  # A redirect can then often redirect the end-user to a URL on :8080, where it should be :80.
  # This may need fine tuning on your setup.
  # To prevent accidental replace, we only filter the 301/302 redirects for now.
  if (beresp.status == 301 || beresp.status == 302) {
    set beresp.http.Location = regsub(beresp.http.Location, ":[0-9]+", "");
  }

###
### Overall TTL
### Note: The TTL is designed to be somewhat aggressive here, to keep things in cache.
###
  # Lets get this party started.
  # This will keep things in cache longer
  if (beresp.ttl &gt; 0s) {
  unset beresp.http.expires;
  set beresp.http.cache-control = "max-age=900";
  set beresp.ttl = 4d; # how long you cache objects
  set beresp.http.magicmarker = "1";
  }

  # Allow stale content, in case the backend goes down.
  # make Varnish keep all objects for x hours beyond their TTL
  set beresp.grace = 12h;

###
### Static Files
###
  # Enable cache for all static files
  # Monitor your cache size, if you get data nuked out of it, consider giving up the static file cache.
  # More reading here: https://ma.ttias.be/stop-caching-static-files/
  if (bereq.url ~ "^[^?]*\.(bmp|bz2|css|doc|eot|flv|gif|ico|jpeg|jpg|js|less|mp[34]|pdf|png|rar|rtf|swf|tar|tgz|txt|wav|woff|xml|zip)(\?.*)?$") {
    set beresp.ttl = 2d; # set a TTL for these optional.
    unset beresp.http.set-cookie;
  }

  # Cache all static files by Removing all cookies for static files - Note: These file extensions are generated by Wordpress WP Super Cache.
  if (bereq.url ~ "^[^?]*\.(html|htm|gz)(\?.*)?$") {
    set beresp.ttl = 1d; # set a TTL for these optional.
    unset beresp.http.set-cookie;
  }

###
### Targeted TTL
###
  # Members section is very dynamic and uses cookies (see cookie settings in vcl_recv).
  if (bereq.url ~ "/members/") {
    set beresp.ttl = 2d;
  }
  # My Shop section is fairly static when browsing the catalog, but woocommerce is passed in vcl_recv.
  if (bereq.url ~ "/psyshop/") {
    set beresp.ttl = 1d;
  }
  # phBB Forum
  # Note: Cookies are dropped for phpBB in vcl_recv which disables the forums cookies, however, logged in users still get a hash.
  # I set the anonymous user as a bot in phpBB admin settings. As bots dont use cookies, this gives 99% hit rate.
  if (bereq.url ~ "/forumPM/") {
    set beresp.ttl = 2h;
  }
  # Long ttl sites
  if (bereq.url ~ "(example.com|example2.com)") {
    set beresp.ttl = 1w;
  }

  # Large static files are delivered directly to the end-user without
  # waiting for Varnish to fully read the file first.
  # Varnish 4 fully supports Streaming, so use streaming here to avoid locking.
  # I do not stream large files from my server, I use a CDN or dropbox, so I have not tested this.
  if (bereq.url ~ "^[^?]*\.(mp[34]|rar|tar|tgz|wav|zip|bz2|xz|7z|avi|mov|ogm|mpe?g|mk[av])(\?.*)?$") {
    unset beresp.http.set-cookie;
    set beresp.do_stream = true;  # Check memory usage it'll grow in fetch_chunksize blocks (128k by default) if the backend doesn't send a Content-Length header, so only enable it for big objects
    set beresp.do_gzip = false;   # Don't try to compress it for storage
  }

  # don't cache response to posted requests or those with basic auth
  if ( bereq.method == "POST" || bereq.http.Authorization ) {
    set beresp.uncacheable = true;
    set beresp.ttl = 120s;
    return (deliver);
        }

  return (deliver);
}


# The routine when we deliver the HTTP request to the user
# Last chance to modify headers that are sent to the client
sub vcl_deliver {
  # Called before a cached object is delivered to the client.

  if (obj.hits &gt; 0) { # Add debug header to see if it's a HIT/MISS and the number of hits, disable when not needed
    set resp.http.X-Cache = "HIT";
  } else {
    set resp.http.X-Cache = "MISS";
  }

  # Please note that obj.hits behaviour changed in 4.0, now it counts per objecthead, not per object
  # and obj.hits may not be reset in some cases where bans are in use. See bug 1492 for details.
  # So take hits with a grain of salt
  set resp.http.X-Cache-Hits = obj.hits;

  # Remove some headers: PHP version
   unset resp.http.X-Powered-By;

  # Remove some headers: Apache version &amp; OS
  unset resp.http.Server;
  unset resp.http.X-Drupal-Cache;
  unset resp.http.X-Varnish;
  unset resp.http.Age;
  unset resp.http.Via;
  unset resp.http.Link;
  unset resp.http.X-Generator;

  if (resp.http.magicmarker) {
  unset resp.http.magicmarker;
  set resp.http.age = "0";
  }

  return (deliver);
}



sub vcl_synth {
  if (resp.status == 720) {
    # We use this special error status 720 to force redirects with 301 (permanent) redirects
    # To use this, call the following from anywhere in vcl_recv: return (synth(720, "http://host/new.html"));
    set resp.http.Location = resp.reason;
    set resp.status = 301;
    return (deliver);
  } elseif (resp.status == 721) {
    # And we use error status 721 to force redirects with a 302 (temporary) redirect
    # To use this, call the following from anywhere in vcl_recv: return (synth(720, "http://host/new.html"));
    set resp.http.Location = resp.reason;
    set resp.status = 302;
    return (deliver);
  }

  return (deliver);
}


sub vcl_fini {
  # Called when VCL is discarded only after all requests have exited the VCL.
  # Typically used to clean up VMODs.

  return (ok);
}

100

101

102

103

104

105

106

107

108

109

110

111

112

113

114

115

116

117

118

119

120

121

122

123

124

125

126

127

128

129

130

131

132

133

134

135

136

137

138

139

140

141

142

143

144

145

146

147

148

149

150

151

152

153

154

155

156

157

158

159

160

161

162

163

164

165

166

167

168

169

170

171

172

173

174

175

176

177

178

179

180

181

182

183

184

185

186

187

188

189

190

191

192

193

194

195

196

197

198

199

200

201

202

203

204

205

206

207

208

209

210

211

212

213

214

215

216

217

218

219

220

221

222

223

224

225

226

227

228

229

230

231

232

233

234

235

236

237

238

239

240

241

242

243

244

245

246

247

248

249

250

251

252

253

254

255

256

257

258

259

260

261

262

263

264

265

266

267

268

269

270

271

272

273

274

275

276

277

278

279

280

281

282

283

284

285

286

287

288

289

290

291

292

293

294

295

296

297

298

299

300

301

302

303

304

305

306

307

308

309

310

311

312

313

314

315

316

317

318

319

320

321

322

323

324

325

326

327

328

329

330

331

332

333

334

335

336

337

338

339

340

341

342

343

344

345

346

347

348

349

350

351

352

353

354

355

356

357

358

359

360

361

362

363

364

365

366

367

368

369

370

371

372

373

374

375

376

377

378

379

380

381

382

383

384

385

386

387

388

389

390

391

392

393

394

395

396

397

398

399

400

401

402

403

404

405

406

407

408

409

410

411

412

413

414

415

416

417

418

419

420

421

422

423

424

425

426

427

# The Psynaptic Media Varnish Config by Psynaps

# Based on many templates including

# https://github.com/mattiasgeniar/varnish-4.0-configuration-templates/blob/master/default.vcl

vcl 4.0;

import std;

import directors;

backend server1 {

.host = "127.0.0.1"; # IP or Hostname of backend

.port = "8080"; # Port Apache or whatever is listening

.max_connections = 800; # That's it

.first_byte_timeout = 300s; # How long to wait before we receive a first byte from our backend?

.connect_timeout = 300s; # How long to wait for a backend connection?

.between_bytes_timeout = 300s; # How long to wait between bytes received from our backend?

}

# Only allow purging from specific IPs

acl purge {

"localhost";

"127.0.0.1";

"104.131.26.178"; # eth0

"10.132.122.116"; # eth1

"psynapticmedia.com";

}

sub vcl_init {

# Called when VCL is loaded, before any requests pass through it. Typically used to initialize VMODs.

new vdir = directors.round_robin();

vdir.add_backend(server1);

#vdir.add_backend(server2);

#vdir.add_backend(server3);

}

sub vcl_recv {

# Called at the beginning of a request, after the complete request has been received and parsed.

# Its purpose is to decide whether or not to serve the request, how to do it, and, if applicable,

# which backend to use.

# also used to modify the request

# send all traffic to the vdir director

set req.backend_hint = vdir.backend();

# TURN OFF CACHE when needed (just uncomment this only when needed)

# return(pass);

# Allow purging from ACL

if (req.method == "PURGE") {

if (!client.ip ~ purge) {

return(synth(405,"Not allowed."));

}

return (purge);

}

# Normalize the header, remove the port (in case you're testing this on various TCP ports)

set req.http.Host = regsub(req.http.Host, ":[0-9]+", "");

# set or append the client.ip to X-Forwarded-For header. Important for logging and correct IPs.

if (req.restarts == 0) {

if (req.http.X-Forwarded-For) {

set req.http.X-Forwarded-For = req.http.X-Forwarded-For + ", " + client.ip;

} else {

set req.http.X-Forwarded-For = client.ip;

}

###

### Do not Cache: special cases

###

# Do not cache AJAX requests.

if (req.http.X-Requested-With == "XMLHttpRequest") {

return(pass);

}

# Post requests will not be cached

if (req.http.Authorization || req.method == "POST") {

return (pass);

}

# Only cache GET or HEAD requests. This makes sure the POST requests are always passed.

#if (req.method != "GET" && req.method != "HEAD") {

# return (pass);

# Dont Cache Wordpress post pages and edit pages

if (req.url ~ "(wp-admin|post\.php|edit\.php|wp-login)") {

return(pass);

}

if (req.url ~ "/wp-cron.php" || req.url ~ "preview=true") {

return (pass);

}

# Woocommerce

if (req.url ~ "(cart|my-account|checkout|addons)") {

return (pass);

}

if ( req.url ~ "\?add-to-cart=" ) {

return (pass);

}

# Paid memberships Pro PMP

if ( req.url ~ "(membership-account|membership-checkout)" ) {

return (pass);

}

# Wordpress Social Login Plugin. Note: Need to develop this. Please share if you have an example.

if (req.url ~ "(wordpress-social-login|wp-social-login)") {

return (pass);

}

# WP-Affiliate

if ( req.url ~ "\?ref=" ) {

return (pass);

}

# phpBB Logged in users and ACP

if ( req.url ~ "(/forumPM/adm/|ucp.php?mode=|\?mode=edit)" ) {

return (pass);

}

###

### http header Cookie

### Remove some cookies (if found)

### Cache This Stuff

###

# https://www.varnish-cache.org/docs/4.0/users-guide/increasing-your-hitrate.html#cookies

### COOKIE MADNESS.

# Remove the "has_js" cookie

set req.http.Cookie = regsuball(req.http.Cookie, "has_js=[^;]+(; )?", "");

# Remove any Google Analytics based cookies

set req.http.Cookie = regsuball(req.http.Cookie, "__utm.=[^;]+(; )?", "");

set req.http.Cookie = regsuball(req.http.Cookie, "_ga=[^;]+(; )?", "");

set req.http.Cookie = regsuball(req.http.Cookie, "utmctr=[^;]+(; )?", "");

set req.http.Cookie = regsuball(req.http.Cookie, "utmcmd.=[^;]+(; )?", "");

set req.http.Cookie = regsuball(req.http.Cookie, "utmccn.=[^;]+(; )?", "");

# Remove the Quant Capital cookies (added by some plugin, all __qca)

set req.http.Cookie = regsuball(req.http.Cookie, "__qc.=[^;]+(; )?", "");

# Remove the wp-settings-1 cookie

set req.http.Cookie = regsuball(req.http.Cookie, "wp-settings-1=[^;]+(; )?", "");

# Remove the wp-settings-time-1 cookie

set req.http.Cookie = regsuball(req.http.Cookie, "wp-settings-time-1=[^;]+(; )?", "");

# Remove the wp test cookie

set req.http.Cookie = regsuball(req.http.Cookie, "wordpress_test_cookie=[^;]+(; )?", "");

# Remove the phpBB cookie. This will help us cache bots and anonymous users.

set req.http.Cookie = regsuball(req.http.Cookie, "style_cookie=[^;]+(; )?", "");

set req.http.Cookie = regsuball(req.http.Cookie, "phpbb3_psyfx_track=[^;]+(; )?", "");

# Remove the cloudflare cookie

set req.http.Cookie = regsuball(req.http.Cookie, "__cfduid=[^;]+(; )?", "");

# Remove the PHPSESSID in members area cookie

set req.http.Cookie = regsuball(req.http.Cookie, "PHPSESSID=[^;]+(; )?", "");

# Are there cookies left with only spaces or that are empty?

if (req.http.cookie ~ "^\s*$") {

unset req.http.cookie;

}

# MEGA DROP. Drop ALL cookies sent to WordPress, except those originating from the URLs defined.

# This increases HITs significantly, but be careful it can also break plugins that need cookies.

# Note: The /members/ directory had problems with PMP login and social login plugin.

# Adding it to the exclude list here (and including it below in the "Retain cookies" list) fixed login.

# This works better than than other cookie removal examples found on varnish's website.

# Note phpBB directory (forumPM) also passes cookies here.

if (!(req.url ~ "(wp-login|wp-admin|cart|my-account|checkout|addons|wordpress-social-login|wp-login\.php|forumPM|members)")) {

unset req.http.cookie;

}

# Normalize the query arguments.

# Note: Placing this above the "do not cache" section breaks some WP theme elements and admin functionality.

set req.url = std.querysort(req.url);

# Large static files are delivered directly to the end-user without

# waiting for Varnish to fully read the file first.

# Varnish 4 fully supports Streaming, so see do_stream in vcl_backend_response() to witness the glory.

if (req.url ~ "^[^?]*\.(mp[34]|rar|tar|tgz|wav|zip|bz2|xz|7z|avi|mov|ogm|mpe?g|mk[av])(\?.*)?$") {

unset req.http.Cookie;

return (hash);

}

# Cache all static files by Removing all cookies for static files

# Remember, do you really need to cache static files that don't cause load? Only if you have memory left.

# Here I decide to cache these static files. For me, most of them are handled by the CDN anyway.

if (req.url ~ "^[^?]*\.(bmp|bz2|css|doc|eot|flv|gif|ico|jpeg|jpg|js|less|pdf|png|rtf|swf|txt|woff|xml)(\?.*)?$") {

unset req.http.Cookie;

return (hash);

}

# Cache all static files by Removing all cookies for static files - These file extensions are generated by WP Super Cache.

if (req.url ~ "^[^?]*\.(html|htm|gz)(\?.*)?$") {

unset req.http.Cookie;

return (hash);

}

# Do not cache Authorized requests.

if (req.http.Authorization) {

return(pass);

}

# Cache all others requests.

# Note Varnish v4: vcl_recv must now return hash instead of lookup

return (hash);

}

sub vcl_pipe {

# Called upon entering pipe mode.

# In this mode, the request is passed on to the backend, and any further data from both the client

# and backend is passed on unaltered until either end closes the connection. Basically, Varnish will

# degrade into a simple TCP proxy, shuffling bytes back and forth. For a connection in pipe mode,

# no other VCL subroutine will ever get called after vcl_pipe.

# Note that only the first request to the backend will have

# X-Forwarded-For set. If you use X-Forwarded-For and want to

# have it set for all requests, make sure to have:

# set bereq.http.connection = "close";

# here. It is not set by default as it might break some broken web

# applications, like IIS with NTLM authentication.

# set bereq.http.Connection = "Close";

return (pipe);

}

sub vcl_pass {

# Called upon entering pass mode. In this mode, the request is passed on to the backend, and the

# backend's response is passed on to the client, but is not entered into the cache. Subsequent

# requests submitted over the same client connection are handled normally.

# return (pass);

}

# The data on which the hashing will take place

sub vcl_hash {

# Called after vcl_recv to create a hash value for the request. This is used as a key

# to look up the object in Varnish.

hash_data(req.url);

if (req.http.host) {

hash_data(req.http.host);

} else {

hash_data(server.ip);

}

# hash cookies for requests that have them

if (req.http.Cookie) {

hash_data(req.http.Cookie);

}

# If the client supports compression, keep that in a different cache

if (req.http.Accept-Encoding) {

hash_data(req.http.Accept-Encoding);

}

return (lookup);

}

# Handle the HTTP request coming from our backend

sub vcl_backend_response {

# Called after the response headers has been successfully retrieved from the backend.

# Sometimes, a 301 or 302 redirect formed via Apache's mod_rewrite can mess with the HTTP port that is being passed along.

# This often happens with simple rewrite rules in a scenario where Varnish runs on :80 and Apache on :8080 on the same box.

# A redirect can then often redirect the end-user to a URL on :8080, where it should be :80.

# This may need fine tuning on your setup.

# To prevent accidental replace, we only filter the 301/302 redirects for now.

if (beresp.status == 301 || beresp.status == 302) {

set beresp.http.Location = regsub(beresp.http.Location, ":[0-9]+", "");

}

###

### Overall TTL

### Note: The TTL is designed to be somewhat aggressive here, to keep things in cache.

###

# Lets get this party started.

# This will keep things in cache longer

if (beresp.ttl > 0s) {

unset beresp.http.expires;

set beresp.http.cache-control = "max-age=900";

set beresp.ttl = 4d; # how long you cache objects

set beresp.http.magicmarker = "1";

}

# Allow stale content, in case the backend goes down.

# make Varnish keep all objects for x hours beyond their TTL

set beresp.grace = 12h;

###

### Static Files

###

# Enable cache for all static files

# Monitor your cache size, if you get data nuked out of it, consider giving up the static file cache.

# More reading here: https://ma.ttias.be/stop-caching-static-files/

if (bereq.url ~ "^[^?]*\.(bmp|bz2|css|doc|eot|flv|gif|ico|jpeg|jpg|js|less|mp[34]|pdf|png|rar|rtf|swf|tar|tgz|txt|wav|woff|xml|zip)(\?.*)?$") {

set beresp.ttl = 2d; # set a TTL for these optional.

unset beresp.http.set-cookie;

}

# Cache all static files by Removing all cookies for static files - Note: These file extensions are generated by Wordpress WP Super Cache.

if (bereq.url ~ "^[^?]*\.(html|htm|gz)(\?.*)?$") {

set beresp.ttl = 1d; # set a TTL for these optional.

unset beresp.http.set-cookie;

}

###

### Targeted TTL

###

# Members section is very dynamic and uses cookies (see cookie settings in vcl_recv).

if (bereq.url ~ "/members/") {

set beresp.ttl = 2d;

}

# My Shop section is fairly static when browsing the catalog, but woocommerce is passed in vcl_recv.

if (bereq.url ~ "/psyshop/") {

set beresp.ttl = 1d;

}

# phBB Forum

# Note: Cookies are dropped for phpBB in vcl_recv which disables the forums cookies, however, logged in users still get a hash.

# I set the anonymous user as a bot in phpBB admin settings. As bots dont use cookies, this gives 99% hit rate.

if (bereq.url ~ "/forumPM/") {

set beresp.ttl = 2h;

}

# Long ttl sites

if (bereq.url ~ "(example.com|example2.com)") {

set beresp.ttl = 1w;

}

# Large static files are delivered directly to the end-user without

# waiting for Varnish to fully read the file first.

# Varnish 4 fully supports Streaming, so use streaming here to avoid locking.

# I do not stream large files from my server, I use a CDN or dropbox, so I have not tested this.

if (bereq.url ~ "^[^?]*\.(mp[34]|rar|tar|tgz|wav|zip|bz2|xz|7z|avi|mov|ogm|mpe?g|mk[av])(\?.*)?$") {

unset beresp.http.set-cookie;

set beresp.do_stream = true; # Check memory usage it'll grow in fetch_chunksize blocks (128k by default) if the backend doesn't send a Content-Length header, so only enable it for big objects

set beresp.do_gzip = false; # Don't try to compress it for storage

}

# don't cache response to posted requests or those with basic auth

if ( bereq.method == "POST" || bereq.http.Authorization ) {

set beresp.uncacheable = true;

set beresp.ttl = 120s;

return (deliver);

}

return (deliver);

}

# The routine when we deliver the HTTP request to the user

# Last chance to modify headers that are sent to the client

sub vcl_deliver {

# Called before a cached object is delivered to the client.

if (obj.hits > 0) { # Add debug header to see if it's a HIT/MISS and the number of hits, disable when not needed

set resp.http.X-Cache = "HIT";

} else {

set resp.http.X-Cache = "MISS";

}

# Please note that obj.hits behaviour changed in 4.0, now it counts per objecthead, not per object

# and obj.hits may not be reset in some cases where bans are in use. See bug 1492 for details.

# So take hits with a grain of salt

set resp.http.X-Cache-Hits = obj.hits;

# Remove some headers: PHP version

unset resp.http.X-Powered-By;

# Remove some headers: Apache version & OS

unset resp.http.Server;

unset resp.http.X-Drupal-Cache;

unset resp.http.X-Varnish;

unset resp.http.Age;

unset resp.http.Via;

unset resp.http.Link;

unset resp.http.X-Generator;

if (resp.http.magicmarker) {

unset resp.http.magicmarker;

set resp.http.age = "0";

}

return (deliver);

}

sub vcl_synth {

if (resp.status == 720) {

# We use this special error status 720 to force redirects with 301 (permanent) redirects

# To use this, call the following from anywhere in vcl_recv: return (synth(720, "http://host/new.html"));

set resp.http.Location = resp.reason;

set resp.status = 301;

return (deliver);

} elseif (resp.status == 721) {

# And we use error status 721 to force redirects with a 302 (temporary) redirect

# To use this, call the following from anywhere in vcl_recv: return (synth(720, "http://host/new.html"));

set resp.http.Location = resp.reason;

set resp.status = 302;

return (deliver);

}

return (deliver);

}

sub vcl_fini {

# Called when VCL is discarded only after all requests have exited the VCL.

# Typically used to clean up VMODs.

return (ok);

}

Whats missing?

– WordPress Purge needs to be implemented and tested.
– Smarter grace period.
– Others? Leave me your comments!

How to watch the magic

In the console, check your HIT and MISS. -w 10 refreshes every 10 seconds

varnishstat -w 10

1	varnishstat -w 10

Realtime log for troubleshooting.

varnishncsa -F "%m %T %{Varnish:handling}x %U"

1	varnishncsa -F "%m %T %{Varnish:handling}x %U"

Helpful Resources and Examples

https://github.com/mattiasgeniar/varnish-4.0-configuration-templates
https://wordpress.org/support/topic/good-varnish-4-defaultvcl
https://gist.github.com/nadirlc/46987b42447cf8e3be79

Tags:

Join the discussion 5 Comments

Josh Johnson says:
06/10/2015 at 12:46 pm
Josh Johnson liked this on Facebook.
Log in to Reply
Alex Macpherson says:
06/10/2015 at 8:54 pm
Alex Macpherson liked this on Facebook.
Log in to Reply
Ryan says:
09/12/2015 at 12:04 am
Wow, this worked, thank you so much for this. Was pulling my hair out since every time I added a product to cart it would remove it. Nice work!
Log in to Reply
Manuel says:
11/01/2015 at 8:12 am
Hi there,
your Vlc is working well about no Error, i mean a see no different About the Caching and Response Time.
I need a Solution for the “Leverage browser caching” and the “request size” of my Page.
You have a idea?
cheers
Manuel
Log in to Reply
GeekGuy says:
07/12/2016 at 7:19 pm
HI,
Thank you for this great VCL. I am using WC3 Total Cache. It seems I am unable to purge the varnish cache. I noticed in your final comments “Whats missing” you said; WordPress Purge needs to be implemented and tested.. Have you had any feed back on this function? Thank you for your valued time.
Log in to Reply

Varnish 4 Example with Apache, WordPress, Woocommerce, Memberships
